Typhoon HIL604 Real-time Emulator
– Runs the EV model
– Test the communication protocol with DUT
Typhoon HIL Connect Interface
– Charging inlet
– Communication protocol to HIL604
Power Amplifier
– Bidirectional charge/discharge power
– Source and sink power to and from DUT
